Yamaha XS650 Ignition System by PamcoPete |
|||
Technology: Hall effect sensor, IGBT
coil driver Simple three wire installation: Battery, ground and coil. No external box of tricks. Plate milled from high quality aluminum. Rotor with four magnets made from a solid billet of aluminum on a CNC machine.
For more information, or if you have bought a system and need assistance, Email:
|
If you have a ’71 to ’79 model, then you will also
need a dual output coil, such as Installing the coils in '71 to '79 Models Installing the New 17-6903 Coil in '80 to '83 Models If you have an ’80 to ’83 model, you can use the stock coil or MikesXS coil, but you will also need the following parts, also available from: www.mikesxs.comPoints advance rod #14-0650 Auto advance unit #14-0652 Breaker plate screws #14-0655 Advance locating pin #14-0653 Brass bushings #05-0032 (3) Thank you for your interest, PamcoPete |
PAMCO Hall Effect Ignition System The system is $89.95 plus $6 Priority Mail in the US and Canada. Email pete@yamahaxs650.com for shipping quote to other countries.
I developed this system in answer to the need for a low cost, reliable electronic ignition system to replace the points on the Yamaha XS650, and the factory TCI electronic system. This system has a very low parts count, only two active electronic components and two discrete passive components. The system incorporates a Hall effect sensor and a purpose built IBGT coil driver transistor, the same one that is used on many automobile electronic ignition systems as well as the latest "Coil on Plug" systems. Each system is assembled to the highest standard and individually tested before shipping. The system comes with a one year warranty. Thank you, PamcoPeteLog on to the XS650 Garage USA for everything XS650!! Go to the "engine/electrical" section to read what the members have to say about the system! And.....while you are there, sign up to be a member!! It's FREE!
|
||
